| CPU |
Embedded 32bit RISC MCU Andes D10F |
| Flash |
16Mbit, SPI Flash |
| Memory |
Built-in 128KB ROM +512KB SRAM |
| Wifi Standard |
802.11b/g/n |
| I/O Interface |
GPIO, PWM, UART, I2C, SPI, ADC,… |
| Function |
2.4GHz WLAN + BLE 5.0 |
| Antenna_Type |
External Antenna
IPEX Connector |
| Tx Power |
802.11b: 18dBm
802.11g: 14dBm
802.11n: 14dBm
BLE: 5dBm |
| Rx Sensitivity |
802.11b: -83dBm (11Mbps)
802.11g: -73dBm (54Mbps)
802.11n: -69dBm (HT40,MCS7)
BLE: -91dBm |
| Security |
WEP 64/128, WPA, WPA2 |
| Dimension |
12mm(L)*12mm(W)*1.5(H) mm |
| Power Consumption |
2.7VDC~3.6VDC |
