| CPU |
Embedded 32bit RISC N9 MCU |
| Flash |
8Mbit, SPI Flash |
| Memory |
Built-in RAM 384KB RAM |
| Wifi Standard |
802.11 b/g/n |
| I/O Interface |
GPIO,PWM,UART,I2C,SPI,SDIO,ADC |
| Function |
2.4GHz High-power WLAN |
| Antenna_Type |
External Antenna |
| Tx Power |
802.11b: 23dBm (5VDC)
802.11g: 20dBm (5VDC)
802.11n: 19dBm (5VDC) |
| Rx Sensitivity |
802.11b: -92dBm
802.11g: -79dBm
802.11n: -70dBm |
| Security |
WEP 64/128, WPA, WPA2 |
| Dimension |
16.0mm(L)*14.0mm(W)*2.0mm(H) |
| Power Consumption |
3.3VDC~5.0VDC |
