| Main Chip |
SV6255P |
| Type |
WLAN 2.4GHz+5G, 1T1R
Bluetooth v2.1/3.0/4.2 |
| Memory |
Embedded SRAM |
| Wifi Standard |
802.11 a/b/g/n |
| Host Interface |
USB |
| Application |
Tablet, OTT box, IPCAM, Portable devices |
| Antenna_Type |
External Antenna |
| Tx Power |
802.11b: 18dBm (2.4GHz)
802.11g: 14dBm (2.4GHz)
802.11n: 14dBm (2.4GHz)
802.11a: 14dBm (5GHz)
802.11n: 14dBm (5GHz) |
| Rx Sensitivity |
802.11b: -88dBm (11Mbps)
802.11g: -73dBm (54Mbps)
802.11n: -69dBm (MCS7/HT40/2.4GHz)
802.11a: -70dBm (54Mbps)
802.11n: -66dBm (MCS7/HT40/5GHz) |
| Security |
WEP 64/128, WPA, WPA2 |
| Dimension |
13mm(L)*12.2mm(W)*1.5(H) mm |
| Power Consumption |
3.3VDC |
