| CPU |
Embedded 32bit RISC MCU |
| Flash |
16Mbit, SPI Flash |
| Memory |
Built-in 256KB SRAM |
| Wifi Standard |
802.11b/g/n |
| I/O Interface |
GPIO, PWM, UART, I2C, SPI, ADC,… |
| Function |
2.4GHz WLAN + BLE 5.2 |
| Antenna_Type |
Printed Antenna
IPEX Connector |
| Tx Power |
802.11b: 17dBm
802.11g: 15dBm
802.11n: 14dBm
BLE: 5dBm |
| Rx Sensitivity |
802.11b: -89dBm (11Mbps)
802.11g: -75dBm (54Mbps)
802.11n: -68dBm (HT40,MCS7)
BLE: -85dBm |
| Security |
WEP 64/128, WPA, WPA2 |
| Dimension |
24.0mm(L)*16mm(W)*2.0(H) mm (w/ antenna) |
| Power Consumption |
2.7VDC~3.6VDC |
