| CPU |
Embedded 32bit Andes-N10 MCU |
| Flash |
16Mbit, SPI Flash |
| Memory |
Built-in 128KB ROM +192KB RAM |
| Wifi Standard |
802.11 a/b/g/n |
| I/O Interface |
GPIO, PWM, UART, I2S, SPI, ADC,… |
| Function |
AP, STA, AP+STA Mode |
| Antenna_Type |
Printed Antenna / IPEX Connector |
| Tx Power |
802.11b: 18dBm (2.4GHz)
802.11g: 14dBm (2.4GHz)
802.11n: 14dBm (2.4GHz)
802.11a: 14dBm (5GHz)
802.11n: 14dBm (5GHz) |
| Rx Sensitivity |
802.11b: -88dBm (11Mbps)
802.11g: -73dBm (54Mbps)
802.11n: -69dBm (MCS7/HT40/2.4GHz)
802.11a: -70dBm (54Mbps)
802.11n: -66dBm (MCS7/HT40/5GHz) |
| Security |
WEP 64/128, WPA, WPA2 |
| Dimension |
26.5mm(L)*18mm(W)*3.0(H) mm (w/ antenna) |
| Power Consumption |
3.3VDC |
