| CPU |
Embedded 32bit Real-M300 CPU |
| Flash |
16Mbit, SPI Flash |
| Memory |
Built-in 4MB+256KB RAM |
| Wifi Standard |
802.11 b/g/n |
| I/O Interface |
GPIO, PWM, UART, I2C, SPI, SDIO,… |
| Function |
2.4GHz WLAN + BLE 4.2 |
| Antenna_Type |
Printed Antenna
IPEX Connector |
| Tx Power |
802.11b: 17dBm
802.11g: 15dBm
802.11n: 14dBm
BLE: 5dBm |
| Rx Sensitivity |
802.11b: -88dBm
802.11g: -74dBm
802.11n: -69dBm
BLE: -98dBm (LE 1M) |
| Security |
WEP 64/128, WPA, WPA2 |
| Dimension |
24mm(L)*16mm(W)*2.0mm(H) |
| Power Consumption |
3.3VDC |
