| CPU |
Embedded 32bit MCU |
| Flash |
4Mbit, SPI Flash |
| Memory |
Built-in eFuse 8 byte
built in RAM 100KB |
| Wifi Standard |
802.11 b/g/n |
| I/O Interface |
GPIO*1, UART |
| Function |
AP / Station Mode |
| Antenna_Type |
Printed Antenna
IPEX Connector
External Antenna |
| Tx Power |
802.11b: 16dBm
802.11g: 14dBm
802.11n: 13dBm |
| Rx Sensitivity |
802.11b: -85dBm
802.11g: -72dBm
802.11n: -68dBm |
| Security |
WEP 64/128, WPA, WPA2 |
| Dimension |
21mm(L)*16mm(W)*2.7(H) mm (w/ antenna) |
| Power Consumption |
3.3VDC |
