| CPU |
MIPS 24Kc CPU with 64KB(I)/32KB(D) Cache |
| Flash |
128Mbit/256Mbit, SPI Flash |
| Memory |
Built-in ROM 94KB+RAM 16KB+DDR2 16MB |
| Wifi Standard |
802.11 b/g/n |
| I/O Interface |
10/100 LAN, PCIE, USB, SDIO, SPI, I2S, UART, I2C,… |
| Function |
AP/STA/AP+STA/Repeater Mode |
| Antenna_Type |
External Antenna |
| Tx Power |
802.11b: 17dBm
802.11g: 15dBm
802.11n: 14dBm |
| Rx Sensitivity |
802.11b: -85dBm
802.11g: -70dBm
802.11n: -66dBm (HT40) |
| Security |
WEP 64/128, WPA, WPA2 |
| Dimension |
32mm(L)*27mm(W)*2(H) mm |
| Power Consumption |
3.3VDC |
